Heavy-Duty Squat Hydraulic Bottle Jack – 20,000kg Capacity

This Heavy-Duty Squat Hydraulic Bottle Jack is designed for demanding lifting applications where substantial lifting capacity is required but available clearance beneath the load is limited.

Featuring an impressive 20,000kg (20 tonne) Working Load Limit and a low minimum height of just 191mm, the squat-style construction makes this jack particularly useful for heavy vehicles, trucks, agricultural equipment, machinery and industrial applications where a conventional taller bottle jack may not fit.

The hydraulic lifting mechanism provides 113mm of hydraulic travel, while an additional 65mm of adjustment allows the lifting point to be positioned to suit the application. Fully extended, the jack provides a maximum height of 356mm.

Designed for professional workshop and heavy-duty use, this bottle jack complies with Australian/New Zealand Standard AS/NZS 2693-2007.

Features & Benefits:

• Heavy-duty squat-style hydraulic bottle jack
• Massive 20,000kg (20 tonne) Working Load Limit
• Low-profile 191mm minimum height
• Ideal where clearance beneath the lifting point is restricted
• 113mm hydraulic lifting travel
• Additional 65mm adjustment height
• Maximum height of 356mm
• Compact squat design combined with high lifting capacity
• Hydraulic operation provides controlled lifting
• Suitable for demanding professional applications
• Ideal for truck, commercial vehicle and heavy equipment servicing
• Suitable for agricultural and industrial machinery applications
• Excellent addition to professional workshops and service vehicles
• Complies with AS/NZS 2693-2007

Suitable Applications:

• Heavy trucks and commercial vehicles
• Tyre and wheel servicing
• Heavy vehicle workshops
• Agricultural machinery
• Industrial equipment
• Plant and machinery maintenance
• Fleet servicing
• Professional workshop applications

Specifications:

• Item Code: 44190
• Product Type: Squat Hydraulic Bottle Jack
• Working Load Limit: 20,000kg (20 Tonne)
• Minimum Height: 191mm
• Maximum Height: 356mm
• Hydraulic Height: 113mm
• Adjustment Height: 65mm
• Compliance: AS/NZS 2693-2007

Always operate lifting equipment in accordance with the manufacturer's instructions and rated Working Load Limit. A hydraulic jack is a lifting device only; appropriately rated support equipment should be used before working beneath a raised load.
