TR543C 45° Alloy Truck Tyre Valve – Suits Alcoa Aluminium Wheels

Designed for aluminium wheel applications, the TR543C features an O-ring sealing system and metal construction suitable for use with aluminium wheels. Selecting the correct valve is particularly important with Alcoa aluminium truck wheels, helping avoid corrosion issues that can occur when incompatible valve materials are used.

Featuring a compact 45° angled stem, the TR543C helps position the valve for convenient access when inflating tyres, checking tyre pressures and carrying out routine servicing. Its relatively short overall profile makes it particularly useful for compatible wheel configurations where a compact angled valve is required.

Features & Benefits:

• Professional-quality heavy-duty tubeless truck tyre valve
• TR543C valve configuration
• Designed for compatible Alcoa aluminium truck wheels
• Fits 9.7mm valve rim holes
• 45° angled stem configuration
• Compact 1.38" overall length
• 0.98" effective length
• O-ring sealing system
• Designed for use with aluminium wheels
• Helps avoid corrosion associated with incompatible valve materials
• Angled design provides convenient access for inflation and pressure checking
• Heavy-duty metal construction
• Secure clamp-in installation
• Suitable for demanding commercial truck and heavy vehicle applications
• Ideal for truck tyre shops, fleet workshops and heavy vehicle servicing

Specifications:

• Item Code: 24236
• Valve Type: TR543C
• Product Type: Alloy Tubeless Truck Tyre Valve
• Stem Configuration: Angled
• Stem Angle: 45°
• Effective Length: 0.98" (approximately 25mm)
• Overall Length: 1.38" (approximately 35mm)
• Rim Hole Size: 9.7mm
• Seal Type: O-Ring
• Wheel Application: Compatible Alcoa Aluminium Truck Wheels
• Application: Commercial Truck / Heavy Vehicle

Important: Designed for compatible Alcoa aluminium truck wheels manufactured with a 9.7mm valve rim hole. Always confirm the wheel and valve specifications before installation.
